Finisar FTLC9152RGPL 100G SWDM4 QSFP28 LC Duplex 100M MMF 100G Ethernet Multimode Transceiver

TOPSTAR TECHNOLOGY INDUSTRIAL CO., LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Finisar FTLC9152RGPL 100G SWDM4 QSFP28 LC Duplex 100M MMF 100G Ethernet Multimode Transceiver from wholesalers

    Buy cheap Finisar FTLC9152RGPL 100G SWDM4 QSFP28 LC Duplex 100M MMF 100G Ethernet Multimode Transceiver from wholesalers
    • Buy cheap Finisar FTLC9152RGPL 100G SWDM4 QSFP28 LC Duplex 100M MMF 100G Ethernet Multimode Transceiver from wholesalers
    • Buy cheap Finisar FTLC9152RGPL 100G SWDM4 QSFP28 LC Duplex 100M MMF 100G Ethernet Multimode Transceiver from wholesalers
    • Buy cheap Finisar FTLC9152RGPL 100G SWDM4 QSFP28 LC Duplex 100M MMF 100G Ethernet Multimode Transceiver from wholesalers
    • Buy cheap Finisar FTLC9152RGPL 100G SWDM4 QSFP28 LC Duplex 100M MMF 100G Ethernet Multimode Transceiver from wholesalers
    • Buy cheap Finisar FTLC9152RGPL 100G SWDM4 QSFP28 LC Duplex 100M MMF 100G Ethernet Multimode Transceiver from wholesalers

    Finisar FTLC9152RGPL 100G SWDM4 QSFP28 LC Duplex 100M MMF 100G Ethernet Multimode Transceiver

    Ask Lasest Price
    Brand Name : Finisar
    Model Number : FTLC9152RGPL
    Certification : ROHS
    Price : Price is negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram, D/A
    Supply Ability : 800pcs per day
    Delivery Time : 3-4 days
    • Product Details
    • Company Profile

    Finisar FTLC9152RGPL 100G SWDM4 QSFP28 LC Duplex 100M MMF 100G Ethernet Multimode Transceiver

    Finisar FTLC9152RGPL 100G QSFP28 SWDM4 850NM 100M Optical Module


    Parameters

    Fiber Type

    10GBASE-LR4Ethernet

    ConnectorLC
    Lasers and TIAVCSEL and PIN
    Tx Power-3 dBm
    Rx Sensitivity-9.4 dBm
    Extinction Ratio-8.2~-8.8 dbm
    Power Consumption3.5W
    Single Power Supply3.3~5 V

    Finisar’s FTLC9152RGPL 100G QSFP28 transceiver modules are designed for use in 100G Ethernet links over duplex multimode fiber. They are compliant with the QSFP28 MSA1 and IEEE 802.3bm CAUI-42 . Digital diagnostics functions are available via the I2C interface, as specified by the QSFP28 MSA1 and Finisar Application Note AN21675 . The transceiver is RoHS-6 compliant per Directive 2011/65/EU3 , and Finisar Application Note AN-20384 .


    PRODUCT FEATURES


    • Hot-pluggable QSFP28 form factor
    • Supports 103.1Gb/s aggregate bit rate
    • Power dissipation < 3.5W
    • RoHS-6 compliant
    • Commercial case temperature range of 0°C to 70°C
    • Single 3.3V power supply
    • Maximum link length of 100m on OM4 Duplex Multimode Fiber (MMF)
    • 4x25Gb/s 850mm VCSEL-based transmitter
    • 4x25G CAUI-4 electrical interface
    • Duplex LC receptacles
    • I2C management interface

    APPLICATIONS


    • 100G Ethernet over Duplex MMF



    FAQ


    1. Are your Optical Transceivers original?

    Yes, all our optical transceivers are guaranteed 100% original!


    2. What will you do if I found the product has any quality problem?

    We back up every sale with our risk-free money-back guarantee! You can buy with confidence from a company in good faith that has been serving its clients for over 10 years!


    3. What did your company do in terms of quality control?

    We have professional testing equipment and QC team. Every unit will be fully tested with perfect performance before shipping.


    4. What are the trade terms?

    Lead Time: 1 day after confirm your payment (In stock, we need 1 day to fully test them)

    Payment term: Western Union, T/T, Aliexpress Escow, Money Gram

    Warranty: 1 Year


    5. Do you have compatible ones?

    Yes, we have our own brand—Toptrans, including SFP, XFP, SFP+, Bidi in all kinds of specifications.
