Original Finisar FTLX8574D3BCL 10Gb/S 850nm Multimode Datacom SFP+ Transceiver For 10G Fibre Channel

TOPSTAR TECHNOLOGY INDUSTRIAL CO., LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Original Finisar FTLX8574D3BCL 10Gb/S 850nm Multimode Datacom SFP+ Transceiver For 10G Fibre Channel from wholesalers

    Buy cheap Original Finisar FTLX8574D3BCL 10Gb/S 850nm Multimode Datacom SFP+ Transceiver For 10G Fibre Channel from wholesalers
    • Buy cheap Original Finisar FTLX8574D3BCL 10Gb/S 850nm Multimode Datacom SFP+ Transceiver For 10G Fibre Channel from wholesalers

    Original Finisar FTLX8574D3BCL 10Gb/S 850nm Multimode Datacom SFP+ Transceiver For 10G Fibre Channel

    Ask Lasest Price
    Brand Name : Finisar
    Model Number : FTLX8574D3BCL
    Certification : ROHS
    Price : 189$/pcs(Price is negotiable)
    Payment Terms : L/C, T/T, Western Union, MoneyGram, D/A
    Supply Ability : 800pcs per day
    Delivery Time : 3-4 days
    • Product Details
    • Company Profile

    Original Finisar FTLX8574D3BCL 10Gb/S 850nm Multimode Datacom SFP+ Transceiver For 10G Fibre Channel

    Original Finisar FTLX8574D3BCL 10Gb/S 850nm Multimode Datacom SFP+ Transceiver For 10G Fibre Channel​


    Parameters

    Fiber Type

    10GBASE-SR

    ConnectorLC
    Lasers and TIAVCSEL and PIN
    Tx Power-5--1 dBm
    Rx Sensitivity-7.5 dBm
    Extinction Ratio
    Power Consumption1.5W
    Single Power Supply3.3 V


    Finisar’s FTLX8574D3BCL 10Gb/s SFP+ transceivers are designed for use in 10-Gigabit Ethernet links over multimode fiber. They are compliant with SFF-84311 , SFF-84322 , IEEE 802.3-2012 10GBASE-SR/SW3 and 10G Fibre Channel 1200-Mx-SN-I 4 . Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF84725 . The FTLX8574D3BCL is a “limiting module”, i.e., it employs a limiting receiver. Host board designers using an EDC PHY IC should follow the IC manufacturer’s recommended settings for interoperating the host-board EDC PHY with a limiting receiver SFP+ module. The optical transceiver is compliant per the RoHS Directive 2011/65/EU6 . See Finisar Application Note AN-20387 for more details.


    PRODUCT FEATURES OF FTLX8574D3BCL


    • Hot-pluggable SFP+ footprint
    • Supports 9.95 to 10.5 Gb/s bit rates*
    • Power dissipation < 1W
    • RoHS-6 compliant (lead-free)
    • Commercial temperature range -5°C to 70°C
    • Single 3.3Vpower supply
    • Maximum link length of 400m on OM4 MMF
    • Uncooled 850nm VCSEL laser
    • Receiver limiting electrical interface
    • Duplex LC connector
    • Built-in digital diagnostic functions

    APPLICATIONS OF FTLX8574D3BCL

    • 10GBASE-SR/SW 10G Ethernet
    • 1200-Mx-SN-I 10G Fibre Channel




    FAQ OF FTLX8574D3BCL


    1. Are your Optical Transceivers original?

    Yes, all our optical transceivers are guaranteed 100% original!


    2. What will you do if I found the product has any quality problem?

    We back up every sale with our risk-free money-back guarantee! You can buy with confidence from a company in good faith that has been serving its clients for over 10 years!


    3. What did your company do in terms of quality control?

    We have professional testing equipment and QC team. Every unit will be fully tested with perfect performance before shipping.


    4. What are the trade terms?

    Lead Time: 1 day after confirm your payment (In stock, we need 1 day to fully test them)

    Payment term: Western Union, T/T, Aliexpress Escow, Money Gram

    Warranty: 1 Year


    5. Do you have compatible ones?

    Yes, we have our own brand—Toptrans, including SFP, XFP, SFP+, Bidi in all kinds of specifications.
