BR-6505-12-0R Brocade 6505 Fibre Channel Switch 12 Port 0 Sfps

TOPSTAR TECHNOLOGY INDUSTRIAL CO., LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap BR-6505-12-0R Brocade 6505 Fibre Channel Switch 12 Port 0 Sfps from wholesalers

    Buy cheap BR-6505-12-0R Brocade 6505 Fibre Channel Switch 12 Port 0 Sfps from wholesalers
    • Buy cheap BR-6505-12-0R Brocade 6505 Fibre Channel Switch 12 Port 0 Sfps from wholesalers
    • Buy cheap BR-6505-12-0R Brocade 6505 Fibre Channel Switch 12 Port 0 Sfps from wholesalers

    BR-6505-12-0R Brocade 6505 Fibre Channel Switch 12 Port 0 Sfps

    Ask Lasest Price
    Brand Name : Brocade
    Model Number : BR-6505-12-0R
    Certification : CE SA KCC
    Price : Price is negotiable
    Payment Terms : T/T, Western Union, MoneyGram, Paypal,Credit Card
    Supply Ability : 500pcs per month
    Delivery Time : 3-5 working days
    • Product Details
    • Company Profile

    BR-6505-12-0R Brocade 6505 Fibre Channel Switch 12 Port 0 Sfps

    Brocade BR-6505-12-0R Brocade 6505 Fibre Channel Switch With 12Port 0 Sfps


    The Brocade 6505 Switch with Gen 5 Fibre Channel provides exceptional price/performance value, combining flexibility, simplicity, and enterprise-class functionality in an entry-level switch. Gen 5 Fibre Channel is the purpose built, data center-proven network infrastructure for storage, delivering unmatched reliability, simplicity, and 16 Gbps performance. The Brocade 6505 with Gen 5 Fibre Channel and Brocade Fabric Vision technology unleashes the full potential of high density server virtualization, cloud architectures, and next-generation storage.

    Main featuresSystems Architecture
    Power consumption80 W with all 24 ports populated with 16 Gbps SWL optics 60 W for empty chassis with no optics
    ScalabilityFull-fabric architecture with a maximum of 239 switches
    Certified maximum6000 active nodes; 56 switches, 19 hops in Brocade Fabric OS® fabrics; larger fabrics certified as required
    Management access10/100 Mbps Ethernet (RJ-45), in-band over Fibre Channel, serial port (RJ-45), and one USB port
    ISL TrunkingFrame-based Trunking with up to eight 16 Gbps ports per ISL trunk; up to 128 Gbps per ISL trunk. Exchange-based load balancing across ISLs with DPS included in Brocade Fabric OS.
    USBOne USB port for system log file downloads or firmware upgrades
    VibrationOperating: 0.5 g sine, 0.4 grms random, 5 Hz to 500 Hz Non-operating: 2.0 g sine, 1.1 grms random, 5 Hz to 500 Hz
    Power supply

    Base switch includes a single, hot-swappable power supply with integrated system cooling fans.

    Optional dual redundant hot-swappable power supply.


    Exceptional Price/Performance for Growing SAN Workloads The Brocade 6505 combines market leading throughput with an affordable
    switch form factor, making it ideal for growing SAN workloads. The 24 ports produce an aggregate 384 Gbps full duplex throughput; any eight ports can be trunked for 128 Gbps Inter-Switch Links (ISLs). Exchange-based Dynamic Path Selection (DPS) optimizes fabric wide performance and load balancing by automatically routing data to the most efficient and available path in the fabric. It augments Brocade ISL Trunking to provide more effective load balancing in certain configurations. Flexible, Easy-to-Use Entry-Level SAN Switch for Private Cloud Storage To keep pace with growing business demands, data centers are transitioning to highly virtualized, private cloud storage environments. This approach enables organizations to consolidate and simplify their IT resources, resulting in increased business agility and lower capital and operating expenses. But virtualization is not without its challenges. Data centers must keep up with the explosive data growth and dynamic changes driven by virtualized workloads. Selecting the right network is key to realizing the full benefits of these cloud-based architectures.

    FAQ

    Q1. What Brocade SFP optical module can be used on this Brocade 6505 switch?

    A1:57-1000117-01 XBR-000164 57-0000080-01 XBR-000174 etc Brocade 2G 4G 8G 16G whole series SFP optical modules can be used;


    Q2. How does your company do regarding quality control?

    A2: All our Brcoade switch were from formal channels, and we only sell original type products for the past 16 years;


    Q3. What are the trade terms?

    A3: Ex-w, COF, CIP, FOB as client requested;
