    G630 Brocade 48 Port Switch 32G SFP FC BR-G630-48-32G-R

    Ask Lasest Price
    Brand Name : Brocade
    Model Number : BR-G630-48-32G-R
    Certification : CE SA KCC
    Price : Price is negotiable
    Payment Terms : T/T, Western Union, MoneyGram, Paypal,Credit Card
    Supply Ability : 500pcs per month
    Delivery Time : 3-5 working days
    • Product Details
    • Company Profile

    G630 Brocade 48 Port Switch 32G SFP FC BR-G630-48-32G-R

    BR-G630-48-32G-R Brocade G630 Switch 48 Port Activation 32G SFP FC Switch


    Product Description:

    Brocade Gen 6 Fibre Channel is the purpose-built network infrastructure for mission-critical storage, delivering NVMe-ready performance, advanced automation, and comprehensive management to accelerate application performance and drive always-on business operations.

    The Brocade G630 Switch with Gen 6 Fibre Channel and Brocade Fabric Vision technology delivers unmatched 32G performance, industry leading port density, andautomated operations to support storage growth, demanding workloads, and data center consolidation.
    Simplify andConsolidate Cabling with Flexible Q-Flex Ports
    Q-Flex ports are available for flexible Inter-Switch Link (ISL) and device connectivity with industry leading 32G speeds. These ports are designed to support single QSFP connections or fan out to four standard SFP+ connections, enabling administrators to simplify cabling infrastructure. The Ports on Demand (PoD) feature of the Brocade G630 gives organizations the flexibility to mix and add Q-Flex ports at any time.

    Main featuresSystems Architecture
    AC Power consumptionMaximum 942W with all 128 ports operating at 32G (96 ports populated with 32G SWL optics and 8 QSFP ports populated with 4×32G SWL optics).
    Maximum of 495W for empty chassis with no optics in idle configuration
    ScalabilityFull-fabric architecture with a maximum of 239 switches
    Operating environment
    Temperature: 0°C to 40°C/32°F to 104°F
    Humidity: 10% to 85% (non-condensing)
    Management access10/100/1000 Mb/s Ethernet (RJ-45), In-band over Fibre Channel, Serial port (RJ-45), and one USB port
    ISL TrunkingEnterprise Package - includes Fabric Vision, Extended Fabric and ISL Trunking
    USBOne USB port for system log file downloads or firmware upgrades
    VibrationOperating: 0.5g sine, 0.4 grms random, 5 Hz to 500 Hz
    Non-operating: 2.0g sine, 1.1 grms random, 5 Hz to 500 Hz
    Enclosure
    Front-to-back airflow; non-port-side exhaust; port-side intake; 2U
    Back-to-front airflow; non-port-side intake; port-side exhaust; 2U
    Port typesD_Port (ClearLink Diagnostic Port), E_Port, EX_Port, F_Port, AE_Port, optional port-type control
    Media types
    32G FC SFP+ LC connector: SWL, LWL, ELWL
    16G FC SFP+ LC connector: SWL, LWL, ELWL
    10G FC SFP+ LC connector: SWL, LWL
    4x32G FC QSFP+ MPO connector: SWL
    4x32G FC QSFP+ SMF LC connector: 2 km (fixed at 4x32G only)
    4x16G FC QSFP+ MPO connector: SWL
    SecurityDH-CHAP (between switches and end devices), FCAP switch authentication; HTTPS, IP filtering, LDAP with IPv6, OpenLDAP, Port Binding, RADIUS, TACACS+, user-defined Role-Based Access Control (RBAC), Secure Boot, Secure Copy (SCP), Secure Syslog, SFTP, SSH v2, SSL, Switch Binding, Trusted Switch. The Brocade G630 Switch provides up to 12 in-flight encryption and compression ports.
    Size
    Width: 440.00 mm (17.32 in.)
    Height: 86.70 mm (3.41 in.)
    Depth: 609.60 mm (24.00 in.)
    Heat dissipation128 ports at 3512 BTU/hr



    Data centers are under pressure to deliver maximum performance, business intelligence, and operational efficiency to address exponential data growth and dynamic business demands. To gain the performance required, organizations are transitioning to the all-flash data center, which requires a modern storage network that can keep pace with innovations in compute and storage resources. By modernizing the SAN, organizations will be able to maximize productivity and increase the efficiency of their storage investments, even as they rapidly scale their environments. Moreover, the addition of automation technology to Gen 6 Fibre Channel will transform SAN management by simplifying operations and freeing up resources to focus on business optimization and revenue opportunities.
