    Hitachi Brocade SAN Switch HD-G630-96-32G-R 96 Ports 2U Connectivity

    Ask Lasest Price
    Brand Name : Hitachi Brocade
    Model Number : HD-G630-96-32G-R
    Certification : CE SA KCC
    Price : Price is negotiable
    Payment Terms : T/T, Western Union, MoneyGram, Paypal,Credit Card
    Supply Ability : 500pcs per month
    Delivery Time : 3-5 working days
    • Product Details
    • Company Profile

    Hitachi Brocade SAN Switch HD-G630-96-32G-R 96 Ports 2U Connectivity

    Hitachi Brocade HD-G630-96-32G-R 96 Ports 2U Connectivity SAN Switch


    Product Description:

    The Brocade® G630 Switch provides the tools to optimize NVMe storage and automate SAN management tasks. It is a high port density building block with a management platform designed to support application, data, and storage growth. As an NVMe ready switch, the Brocade G630
    allows organizations to seamlessly integrate Brocade Gen 6 Fibre Channel networks with the next generation of flash storage, without a disruptive rip-and replace. In addition, the Brocade G630 features integrated network sensors for advanced monitoring of NVMe workloads, helping to ensure optimal performance.
    The Brocade G630 Switch also delivers new automation capabilities that enable DevOps resources to automate and orchestrate SAN resources
    through open APIs and the Ansible automation engine. With Brocade automation, organizations can quickly and reliably perform resource-intensive tasks, such as provisioning, and operationalize the continuous monitoring of the network, so that tasks can be completed in a fraction of the time. By combining Broadcom’s robust set of data collecting capabilities with automation, organizations can automate repetitive daily tasks and deliver consistent performance by eliminating human error. With the Brocade G630, organizations can seamlessly transition to an all-flash data center and build a foundation to support future innovation and operational efficiency.

    Main featuresSystems Architecture
    AC Power consumption
    Maximum 942W with all 128 ports operating at 32G (96 ports populated with 32G SWL optics and 8 QSFP ports populated with 4×32G SWL optics).
    Maximum of 495W for empty chassis with no optics in idle configuration
    Scalability
    Full-fabric architecture with a maximum of 239 switches
    Operating environment
    Temperature: 0°C to 40°C/32°F to 104°F
    Humidity: 10% to 85% (non-condensing)
    Management access
    10/100/1000 Mb/s Ethernet (RJ-45), In-band over Fibre Channel, Serial port (RJ-45), and one USB port
    ISL Trunking
    Enterprise Package - includes Fabric Vision, Extended Fabric and ISL Trunking
    USBOne USB port for system log file downloads or firmware upgrades
    VibrationOperating: 0.5g sine, 0.4 grms random, 5 Hz to 500 Hz
    Non-operating: 2.0g sine, 1.1 grms random, 5 Hz to 500 Hz
    Enclosure
    Front-to-back airflow; non-port-side exhaust; port-side intake; 2U
    Back-to-front airflow; non-port-side intake; port-side exhaust; 2U
    Port types
    D_Port (ClearLink Diagnostic Port), E_Port, EX_Port, F_Port, AE_Port, optional port-type control
    Media types
    32G FC SFP+ LC connector: SWL, LWL, ELWL
    16G FC SFP+ LC connector: SWL, LWL, ELWL
    10G FC SFP+ LC connector: SWL, LWL
    4x32G FC QSFP+ MPO connector: SWL
    4x32G FC QSFP+ SMF LC connector: 2 km (fixed at 4x32G only)
    4x16G FC QSFP+ MPO connector: SWL
    Security
    DH-CHAP (between switches and end devices), FCAP switch authentication; HTTPS, IP filtering, LDAP with IPv6, OpenLDAP, Port Binding, RADIUS, TACACS+, user-defined Role-Based Access Control (RBAC), Secure Boot, Secure Copy (SCP), Secure Syslog, SFTP, SSH v2, SSL, Switch Binding, Trusted Switch. The Brocade G630 Switch provides up to 12 in-flight encryption and compression ports.
    Size
    Width: 440.00 mm (17.32 in.)
    Height: 86.70 mm (3.41 in.)
    Depth: 609.60 mm (24.00 in.)
    Heat dissipation
    128 ports at 3512 BTU/hr


    Highlights
    • Adapt to storage growth and demanding workloads with the industry’s highest-density 128-port 32G Gen 6 Fibre Channel switch.
    • Optimize performance and ensure reliability with enhanced monitoring for NVMe.
    • Integrate NVMe-ready solutionswithout a rip-and-replace.
    • Accelerate operations with simple and open automation that increases productivity.
    • Simplify end-to-end management of large-scale environments by automating repetitive administrative tasks.
    • Provide proactive, real-time monitoring and alerting of storage I/O health and performance with integrated network sensors.
    • Enable virtual machine (VM) visibility in a storage fabric in order to monitor VM performance, identify VM anomalies, and optimize VM performance.
