    Dell Connectrix DS6620B Fiber Optic Switch 24 Port 32Gb/S Enterprise Network Switch

    Ask Lasest Price
    Brand Name : DELL EMC
    Model Number : DS-6620B
    Certification : CE SA KCC
    Price : Price is negotiable
    Payment Terms : T/T, Western Union, MoneyGram, Paypal,Credit Card
    Supply Ability : 500pcs per month
    Delivery Time : 3-5 working days
    • Product Details
    • Company Profile

    Dell Connectrix DS6620B Fiber Optic Switch 24 Port 32Gb/S Enterprise Network Switch

    Dell EMC Connectrix DS-6620B Switch 24 ports 32 Gb/s Enterprise switch


    EMC Connectrix 6600 series Switch w/ Up to 64 ports. 24-port base DS-6620B

    Product Description:

    DS-6620B is designed to support the SAN requirements of medium-to large sized workgroups as well as that of large enterprises, the Connectrix DS-6620B offers forty-eight SFP+ ports and four QSFP ports in a 1U form factor. Two base models are available which have 24 active 32Gb/s or 16Gb/s ports, populated with 32Gb or 16Gb/s shortwave SFPs. QSFP ports can be used to form dense high performance ISLs with other 32Gb/s switches or directors. QSFPs can also be configured to add up to 16 additional ports. With its speed and port density the DS-6620B can be deployed in any Fibre Channel Storage Area Network (SAN) to enable very dense fabrics in a relatively small package.

    DS-6620B-V2 – Supporting up to 64-ports, this next generation DS-6620B is nearly identical to the current DS-6620B. While both versions offer the same key features and functionalities, there are some differences such as the requirement for FOS 9.0+, the DS-6620B-V2 supports 4Gb/s only on F-port to host/target connections and only has one LED per QSFP port. The number and type of ports is the same as the DS-6620B listed above. Like the DS-6620B, this switch is ideal for medium to large enterprises

    Main featuresSystems Architecture
    AC Power consumption
    DS-6620B and DS-6620B-V2 - 206 WATTS with all 64 ports populated
    Scalability
    from eight to 128 ports
    Operating environment
    Temperature: 0°C to 40°C/32°F to 104°F
    Humidity: 10% to 85% (non-condensing)
    Management access
    10/100/1000 Mb/s Ethernet (RJ-45), In-band over Fibre Channel, Serial port (RJ-45), and one USB port
    ISL Trunking
    Enterprise Package - includes Fabric Vision, Extended Fabric and ISL Trunking
    USBOne USB port for system log file downloads or firmware upgrades
    VibrationOperating: 0.5g sine, 0.4 grms random, 5 Hz to 500 Hz
    Non-operating: 2.0g sine, 1.1 grms random, 5 Hz to 500 Hz
    Enclosure
    There are two air flow options: front-to-rear (FTR) and rear-to-front (RTF)
    Port typesDS-6620B and DS-6620B-V2 - D_Port (ClearLink Diagnostic Port), E_Port, EX_Port, F_Port, AE_Port;optional port-type control Brocade Access Gateway mode: F_Port and NPIV-enabled N_Port
    Hot swappable components
    DS-6620B and DS-6620B-V2 – Dual power supplies with three embedded cooling fan FRUs, SFPs and QSFP optics. The fans are connected to the power supplies and are not themselves replaceable
    Security
    AES-GCM-256 encryption on ISLs; DH-CHAP (between switches and end devices), FCAP switch authentication; HTTPS, IPsec, IP filtering, LDAPwith IPv6, OpenLDAR, Port Binding, RADIUS, TACACS+, user-defined Role-based Access Control (RBAC), Secure Copy (SCP), Secure RPC, Secure Syslog, SSH v2,SSL, Switch Binding, Trusted Switch
    Dimension and weight
    Height x Width x Depth: 1.73x17.32x14.0 inches
    (43.9mmx440mmx355.6mm), 1RU
    Weight with 2 power supplies and no transceivers: 17lbs (7.73kg)
