    Type B Plenum MTP To MTP Fiber Patch Cable 10M 8 Fibers OM4 Multimode

    Ask Lasest Price
    Brand Name : Top-Trans
    Model Number : PT-8OM4MTP-C10
    Certification : CE ROHS
    Price : Price is negotiable
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 20000pcs per month
    Delivery Time : 2-3 working days
    • Product Details
    • Company Profile

    Type B Plenum MTP To MTP Fiber Patch Cable 10M 8 Fibers OM4 Multimode

    10M 8 fibers MTP Female to MTP Female OM4 Multimode Type B, Plenum Elite Trunk Cable


    MTP FiberShield Specifications

    8 Fiber Multimode (OM4) MTP Fiber Cable w/FiberShield with MTP(Female)-MTP(Female) connectors. Use this 5 Meter (Approx. 15ft) for 40G 50/125 (OM4) fiber optic links Type: For 40G Networks - Fiber optic cable for connection between two 40G QSFP+ transceivers with MTP/MPO interfaces or other 10G/40G network links. MTP Polarity Method B (Cross-Connect) - Key-up to Key-up (Polarity A or C optional), MTP-MTP.

    Topstar's 8 fiber MTP cables feature our new and exclusive FiberShield design. The FiberShield structure employs three times (3x) the amount of the PVC jacket and DuPont Kevlar to protect the multitude of delicate optical fibers located inside the cables. This ruggedized cable structure results in a flexible yet robust 4.5mm MTP cable that is 5x stronger than the standard 3.0mm cable.


    • Fiber Optic Patch Cable, 0.5 m - 100 m
    • MTP® (female) UPC to MTP® (female) UPC
    • MTP® connector complies to the MPO standard but ensures lower Insertion Loss
    • 8 Cores for 40G (4x 10G) or 100G (4x 25G) applications
    • Multimode - Fiber grade ITU-T G.651.1


    Fiber TypeOM4 50/125um
    Wavelength850/1300nm
    10G Ethernet Distance400m at 850nm
    40/100G Ethernet Distance150m at 850nm
    Polish TypeUPC to UPC
    Minimum Bend Radius7.5mm
    Attenuation at 850nm≤2.3 dB/km
    Attenuation at 1300nm
    ≤0.6 dB/km
    Installation Tensile Load66N
    Tensile Strength (Long/Short Term)80N/240N


    Use this MTP Multimode Cable for 40G/100G (4 Send - 4 Receive):
    100G QSFP+ SR4 links between two Juniper, Finisar or Cisco QSFP+ transceivers (100GBASE-SR4).
    100G QSFP100 SR4 links between two Cisco, Juniper or Finisar QSFP100 transceivers (100GBASE-SR4).
    40G QSFP+ SR4 links between two Cisco, Finisar or Juniper QSFP+ transceivers (40GBASE-SR4).
    40G QSFP SR4 links between two Cisco, Finisar or Juniper QSFP transceivers (40GBASE-SR4).
    Other 10G/40G/100G links between patch panels and transceivers.
    Genuine MTP Connectors (US Conec). Manufactured using OM4 fiber, standard jacket MTP Fiber Cable w/FiberShield is designed for light to medium duty indoor applications such as data-center racks and desktop/network connections. Optional MTP Elite (US Conec) low loss connectors available.
