    XBR-000420 FC SFP Transceiver ICL QSFP 4×50G FC SML 100M MMF Brocade X7 Use

    Ask Lasest Price
    Brand Name : Brocade
    Model Number : XBR-000420
    Certification : ISO9001, ROHS, CE, FCC
    Price : Negotiable
    Payment Terms : T/T, Western Union, Paypal,
    Supply Ability : 3000pcs per month
    Delivery Time : Negotiable
    • Product Details
    • Company Profile

    XBR-000420 FC SFP Transceiver ICL QSFP 4×50G FC SML 100M MMF Brocade X7 Use

    Brocade X7 Use XBR-000420 Transceiver ICL QSFP 4×50G FC SML 100M MMF

    The Brocade Gen 7 ICL Quad Small Form-Factor Pluggable (QSFP) transceivers, part of the Brocade family of optical transceivers, are optimized for Brocade X7 Director ICL connections. The Brocade Gen 7 ICL QSFP optics are hot-swappable, low-voltage (3.3V) digital diagnostic optical transceivers. This optical transceiver operates over 4-lane parallel multi-mode fiber (MMF), using a nominal wavelength of 850 nm, and a standard SFF-8665 compliant MPO-12 UPC connector.

    • Provides high connectivity reliability through rigorous qualification and certification processes.

    • Provides scalable connectivity for Brocade X7 Director chassis-to chassis interconnect.

    • Operates over 4-lane parallel multimode fiber (MMF) and is QSFP MSA compliant.

    • Uses industry-standard MPO-12 UPC connector.

    • Supports up to 100m link length over OM4 fiber.

    • IEC 60825-1 Class 1/CDRH Class 1 laser, eye-safe.

    • RoHS compliant.

    Parameters

    Data Speed

    4×53.125Gb/s

    Center Wavelength

    850NM

    Fiber Type

    MMF

    Transmission

    70M on OM3, 100M on OM4

    Connector

    Dual LC

    Lasers

    VCSEL + PIN

    Tx power

    -2.0 - +3.0 dBm

    Rx sensitivity

    +5 dBm

    OMA

    -2.0 dBm to +3.0 dBm per channel

    Power Consumption

    4.5 W

    Single Power Supply

    3.3 v

    FAQ

    • Is this genuine Brocade Original Transceiver?

    Yes, Topstar is the top lead Brocade distributor in China, we sell the brand SFP since 2006 and never sell fake or copy brand items.

    • Hong long does the SFP warranty provide?

    For brocade SFP, we offer 30days of free return, one-year of free replacement.

    • How do you send SFP to my place? and how long does it take?


    Yes, we provide door to door shipment via DHL, FEDEX, Aramex and UPS etc logistic services.

    The express logistic generally takes 5-12 days to global.

    ​​

    • Do you have regular stock of this Brocade transceiver?

    Yes, we have regular stock of this model, ready to ship in 3 working days
